  • Class 5.1 - Oxidizing Agents

Oxidising Agent Storage Cabinet - 160L

sc160a

Download the product spec sheet by filling the form below.

Description

The SC160A is an indoor chemical storage cabinet purpose built for Class 5.1 Oxidising Agents (160 litre capacity). Keep oxidising agents away from flammables and other incompatible substances in this double-walled sheet steel cabinet.

Features of the SC160A include: heavy duty shelving that is fully adjustable along 100mm increments; built in flash arrestors and vent openings that sync with your mechanical ventilation system; high-tech polyurethane coating that resists corrosion. The unit is fitted with compliant safety signage and placards.

The SC160A is part of STOREMASTA’s SAFE-T-STORE series — a range of fully compliant chemical stores for keeping Dangerous Goods safe indoors. 100% designed and manufactured in Australia to the highest safety standards (including AS 4326-2008), order your oxidising agent cabinet direct from STOREMASTA today.

Features
  • Double walled sheet steel construction with a 40mm thermic air barrier
  • High capacity liquid tight sump to contain spills - 150mm deep
  • Self-closing, close fitting doors that automatically release in the event of a build-up of pressure within the cabinet
  • Built in flash arrestors and vent openings [for mechanical ventilation systems]
  • Strong fully adjustable shelving perforated for free air movement, 100mm adjustment increments
  • Sequential door closing system
  • Stainless steel pin with continuous hinging for strength and reliability
  • State of the art powder coat finish for high durability and performance
  • Distinct safety signs and directions that comply with AS 1216 and AS 1319
  • Designed and manufactured in full conformance to AS 4326:2008 - The storage and handling of oxidising agents.
Dimensions (mm)
External H 1220 W 1100 D 450
Internal H 973 W 1018 D 370
Storage Capacity
Max Capacity 160L
Winchester Size 0.5L 2.5L 5L
Capacity 225*** 28 10
Drum Size 4L 20L 60L
Capacity 30***** 6 -
Drum Size 205L
Capacity -
***3 Storage levels *****5 storage levels
Calculations based on these package size
Dangerous Goods Compliance Specifications
Complies with AS4326 - 2008
Sump Capacity 56L
Other Specifications
Weight 78.0 kg
Shelf Levels 2
Storage Levels 2
