Gas Bottle Storage - Premium Range G4
GSC4
Description
With advanced gas storage to suit the unique needs of your workplace, the Gas Bottle Storage - Premium Range provides exceptional choice and flexibility.
Compliant with Australian Standards, the G4 solution offers a range of storage options, with capacity for up to 363 aerosols, 25 industrial cylinders, 18 LPG or 50 acetylene cylinders. Simply adjust the shelving and chains to suit your cans, bottles or cylinders.
The G4 gas store also comes equipped with a fold-down ramp for easy loading of gas bottles. Order your Australian designed and made gas store today.
Features
- Heavy duty construction and surface protection for outdoor use
- State of the art powder coat finish for high durability and performance
- Padlockable door for high security
- Concealed heavy duty hinge pins
- Bolt down plates for added security and stability
- Projectile proof construction
- Fold down ramp allowing easy loading and unloading of gas cylinders
- Natural ventilation that complies with AS 4332
- Appropriate warning and safety signage that complies with AS 1216 and AS 1319
- Designed and manufactured in full conformance to AS 4332
Dimensions (mm)
Dimensions (mm)
| External | H 1200 | W 865 | D 828 |
| Internal | H 1160 | W 800 | D 800 |
Storage Capacity
Storage Capacity
| Aerosol Can | 363 (3) |
| Industrial Cylinder | C size | D size | E size | F size - G/K size |
| Capacity | 98 (2) | 25 (1) | 9 (1) | 0 - 0 |
| LPG Cylinder | N size | P size | T size - R size | S size - 90kg |
| Capacity | 18 (2) | 8 (2) | 4 (1) - 4 (1) | 0 - 0 |
| Acelylene Cylinder | D Size - E size - G size |
| Capacity | 50 (2) - 9 (1) - 9 (1) |
Calculations based on these package size
Dangerous Goods Compliance Specifications
Dangerous Goods Compliance Specifications
| Complies with | AS 4332:2004 |
Other Specifications
Other Specifications
| Full Weight | 90 Kg |
| Storage Levels | 3 |
