170L - Flammable Liquid Storage Cabinet

SC170
Description



Class 3 Flammable liquids must be stored in a controlled environment to reduce the risk of flammable vapour emissions, chemical spills and potential ignition. The Storemasta Flammable Liquid Storage Cabinet SC170 is an Australian made Safety Cabinet that meets the stringent requirements of AS 1940.

170L - Flammable Liquid Storage Cabinet features include Storemasta’s patented sequential door closing system SAFE-T-CLOSE® — which delivers a smooth hydraulic action, allowing doors to close firmly and in sequence, every time.  This Flammable Cabinet is equipped with a compliant spill containment sump to capture flammable spills and fully adjustable perforated shelving to encourage natural air flow.

The Storemasta range of Flammable Cabinets are an ideal indoor storage solution, with models available for every hazard class. Choose a Flammable Storage Cabinet that protects your people, property and environment with the highest quality chemical controls on the market.

Features

  • Double walled sheet steel construction with a 40mm thermic air barrier
  • High capacity liquid tight sump to contain spills - 150mm deep
  • Self-closing, close fitting doors that latch at 2 points
  • Built in flash arrestors and vent openings [for mechanical ventilation systems]
  • Strong fully adjustable shelving perforated for free air movement, 100mm adjustment increments
  • Sequential door closing system
  • Stainless steel pin with continuous hinging for strength and reliability
  • State of the art powder coat finish for high durability and performance
  • Distinct safety signs and directions that comply with AS 1216 and AS 1319
  • Designed and Manufactured in full conformance to AS 1940:2017 - The storage and handling of flammable and combustible liquids

Dimensions (mm)

ExternalH 1540W 750D 450
InternalH 1315W 660D 360

Storage Capacity

Max Capacity 170L
Drum Size4L20L60L205L
Capacity15*6*00
*3 storage levels
Calculations based on these package size

Dangerous Goods Compliance Specifications

Complies with AS1940 - 2017
Sump Capacity 36L

Other Specifications

Weight 90.0 kg
Shelf Levels 2 + Base
Storage Levels 3
Shelf Thickness (mm) 28
Shelf spacing (mm) 190
No. of Shelf Lugs 6 (including base level)
