Single Depth Toxic Substance Store - 4 IBC

PR04BB-6
Description

Storemasta's Relocatable Bulk Dangerous Goods Stores are an ideal solution for the storage of large quantities of dangerous goods, without the problems and expense associated with building fixed stores.

Each store is purpose built to specifically comply with your requirements and can include shelving compartments, decanting systems, pump stations, poly bund linings and built-in eyewash facilities.

The Single Depth Toxic Substance Store - 4 IBC has a capacity of 4000 litres, and offers safety and compliance for DG storage in the outdoor environment.

Features

  • Constructed with quality sheet steel
  • Doors which fold back 270° for ease of access when loading and unloading IBC’s with a forklift
  • Easy access: each IBC accessible via forklift
  • ISO locking bars for high security
  • Natural ventilation that complies with AS/NZS 4452:1997
  • Lifting lugs, forklift channels and locating plates
  • Finished in high build 2 pak polyurethane primer and high gloss topcoat, total build thickness minimum of 120 microns
  • Cyclonic proof construction
  • Earth stake and mounting
  • Cambered roof for rainwater run off
  • Liquid tight spill containment sump with compliant capacity
  • Engineered footing details available
  • Suitable for storage of IBC’s and pallets
  • Appropriate warning and safety signage that complies with AS 1216 and AS 1319
  • Designed and manufactured in full conformance to AS/NZS 4452:1997 - The storage and handling of toxic substances

Dimensions (mm)

ExternalH 3445W 2790D 1440
InternalH 2 x 1275 (2650)W 2500D 1225

Storage Capacity

Max Capacity 4000L
IBC 4
Calculations based on these package size

Dangerous Goods Compliance Specifications

Complies with AS/NZS - 4452 - 1997
Sump Capacity 1000L

Other Specifications

Weight 835.3 kg
Storage Levels 2
