Dangerous Goods Fire Suppression System - Monitored - Extra Large
PSA017Increase the safety of your Outdoor Lithium-ion Battery Store, with this monitored fire suppression system.
Delivery battery fire suppression with compliance monitoring, the Dangerous Goods Fire Suppression System - Monitored – Extra Large suppresses battery fires, while triggering an alarm system. This system detects both heat and off-gassing, which is the first sign of a lithium-ion battery fire risk.
The high-tech Fire Indicator panel also offers a Fault Monitoring system and Isolation Function. Annual maintenance is simple with the system’s test module.
This monitored fire suppression system is also available with the optional extra of SMS monitoring, to provide alarms to designated staff 24/7.
Features
- The equipment layout isn’t fixed. It can be moved to accommodate existing internal equipment, ease of maintenance & provide clear paths
- Spacing allowances can be provided to the manufacturer for each piece of equipment
- The FIP can be mounted internally or externally
- External items are IP66
- Generators & cabling have deutsch plugs fitted for ease of maintenance & replacement
- Generators are 304SS & Brackets 316SS
- FIP- Approved to AS7240.0
- Control Panel - Detection and Activation
- Shielded Fire Rated Cable - 2hr
- Linear Heat Detection 180deg C Cable
- 2000g SS Aerosol Generator
- All bracketry stainless steel
- Sign - System Warning Traffolyte - AS4487 General Strobe Sounder unit - IP66 rated
- Test simulator included for maintenance
- Certified to AS5062
- Suitable for:
- Outdoor Lithium-ion Battery Store - Medium - 500570
Dimensions (mm)
| External | H 300 | W 300 | D 185 |
Other Specifications
| Weight | 15.5 kg |
